LOCOPOW

As Is

6 Pin DC CDI Box Can Fit GY6 50cc 70cc 90cc 110cc 125cc 110cc 150cc 200cc 250cc Chinese ATV Quad Go Kart Pit Dirt Bike Roketa Sunl Lance Scooter Moped Motorcycle Is your black box an AC or a DC-CDI? Here are a few tips: * If the bike has no battery then it’s an AC-CDI * Age of your bike? Old bikes are mostly AC whereas news one are more DC… * Search in your Service Manual Technical Specifications for AC-CDI or DC-CDI mention. * Google your bike with ACCDI and DCCDI key words * The only reliable way is to measure the voltage between GROUND and the POWER source input of the CDI while the engine is running. Ie: On a GY6 CDI measure between GND pin 4 and Power pin 6 If 12 to 15volts DC then it’s a DC-CDI If 50 to 100volts AC then it’s an AC-CDI * While the engine is running, disconnect the battery and the regulator, * The engine stall because it has no more +12v then it’s a DC-CDI * The engine still run because it’s powered by the spinning rotor then it’s an AC-CDI If the bike has a 12v battery, a DC-CDI can replace an AC-CDI but on the contrary an AC-CDI cannot replace a DC-CDI ! This CDI Box fit almost all Chinese brandslike TaoTao Buyang Roketa Coolsport NST BMX Kazuma Sunl AIM-EX Baja Panterra Kymco GILERA HANGLONG HAOJIN HAOJUE HONGZHOU HUATIAN JIAJUE JIANSHE JINLUN JMSTAR JONWAY KAITONG KEEWAY KINROAD KYMCO LIFAN LINGBEN LINGTIAN LINHAI LINTEX LONCIN LONGJIA MAWI MEIDUO MOTORRO PIAGGIO QINGQI RHON RIEJU SACHS SHINERA SKYGO SUKIDA VESPA WANGYE XINGYUE XINLING XINTIAN YIBEN YINGANG ZHONGYU ZNEN ZONGSHEN

1 QTY =

PPE4930622

As Is

204 Peterson Drive, Elizabethtown KY 42701
